The 0729-1759-99 Dual Axis RS-232 Inclinometer utilizes a 0717-4318-99 Fredericks TrueTilt? wide range electrolytic tilt sensor and analog signal conditioner. Its robust plastic housing and epoxy potting provide excellent durability and environmental protection. This inclinometer has superior tolerances and unit to unit performance. Its low profile housing and economic design make it an ideal solution for a versatile range of applications in all sectors.

        The 0729-1759-99 inclinometer can utilize any sensor from the Fredericks 0717 series wide range sensors upon customer request. A detailed list of compatible sensors can be found on page 2 in the Related Products section.

技術指標：

類       型：雙軸傾角傳感器

量       程：±60°

精  確 度：≤2.0%,≤7.0%

輸       出：RS232

供電電源：7～16Vdc

電氣連接：電纜

工作溫度：-40℃～+85℃

特       點：高精度，低功耗，IP67，在極端溫度和環境下的卓越性能

典型應用：高空升降平臺調平監控、起重機吊臂角度測量、機器人控制、衛星天線對準、太陽能電池板位置和標高控制、車輪定位系統
